Datasheet Summary
SUBMINIATURE ULTRA-SENSITIVE DIP RELAY
Features
- Low profile for pact board spacing
- DC coils to 48VDC
- Bifurcated crossbar contacts
- Ultra-sensitivity, 84mW pickup
- Life expectancy to 100 million operations
- High switching capacity, 60W, 125VA
- Fits standard 16 pin IC socket
- Epoxy sealed for automatic wave soldering and cleaning
- Meets FCC Part 68.302 1500V lightning surge
- Meets FCC Part 68.304 1000V dielectric
- UL, CUR file E43203
CONTACTS
Arrangement Ratings
Rated Load UL
Material Resistance
DPDT (2 Form C)
Resistive load: Max. switched power: 60W or 125VA Max. switched current: 2A Max. switched voltage: 120VDC or 240VAC
2A at 30VDC 1A at 125VAC Silver nickel,...
