AZ830
Overview
- Low profile for compact board spacing
- DC coils to 48 VDC
- High sensitivity, 96 mW pickup
- Life expectancy to 100 million operations
- High switching capacity, 60 W, 125 VA
- Fits standard 16 pin IC socket d
- Epoxy sealed for automatic wave soldering and cleaning
- Meets FCC Part 68.302 1500 V lightning surge
- Meets FCC Part 68.304 1000 V dielectric
- UL file E43203 (UL1950) e CONTACTS Arrangement u Ratings tin Rated Load UL Material Resistance DPDT (2 Form C) Bifurcated crossbar contacts Resistive load: Max. switched power: 60 W or 125 VA Max. switched current: 2 A Max. switched voltage: 250 VDC or 300 VAC Max. carry current: 3A 2 A at 30 VDC 1 A at 120 VAC Silver alloy, gold clad. < 50 milliohms initially
