AZ9801
Overview
- 70 Amp contact rating - “Super ISO”
- High momentary carry current (500 A)
- High operating temperature (125°C)
- SPST (1 Form A)
- Quick connect terminals
- ISO/TS 16949, ISO9001, ISO14000
- Epoxy sealed version available CONTACTS Arrangement Ratings Material Resistance SPST (1 Form A) Resistive load: Max. switched power: 980 W Max. switched current: 70 A Max. switched voltage: 50 VDC Silver tin oxide < 50 milliohms initially (24 V, 1 A voltage drop method) COIL Power At Pickup Voltage (typical) Max. Continuous Dissipation Temperature Rise Temperature
- 68 W 4.0 W at 20°C (68°F) 56°C (101°F) at nominal coil voltage Max. 155°C (311°F) NOTES
- All values at 20°C (68°F).
- Relay may pull in with less than “Must Operate” value.
