AZEV116
FEATURES
- 16 Amp nominal switching capability
- Isolated NC signal contact for welding monitoring
- Withstands up to 1020 A short circuit current
- Wide contact gap of ≥ 2.25 mm
- Dielectric strength 4 k VRMS
- UL / CUR: E365652
- TÜV: B 088793 0014
- CQC: CQC19002216104
CONTACTS
Arrangement load contact signal contact
Ratings (max.) load contact switched power switched current switched voltage signal contact switched current minimum load
Approved ratings UL/CUR load contact signal contact
TÜV/CQC load contact signal contact
Contact material load contact signal contact
Contact gap load contact
Contact resistance load contact initial typical
SPST-NO (1 Form A) SPST-NC (1 Form B) coupled to load contact (resistive load) 6400 VA 20 A 400 VAC
10 m A at 12 VDC 10 m A, 5 VDC, 50m W
16 A at 277 VAC, resistive, 85°C, 50k cycles 20 A at 277 VAC, resistive, 85°C, 30k cycles 10 m A at 12 VDC, 85°C, 50k cycles
16 A at 400 VAC, resistive, 85°C, 50k cycles 20 A at 277 VAC, resistive, 85°C, 30k cycles...
