FMMT3904
SOT23 NPN SILICON PLANAR SWITCHING TRANSISTORS
ISSUE 2
- SEPTEMBER 94 ✪
PLIMENTARY TYPES
- FMMT3903
- FMMT3905 FMMT3904
- FMMT3906
PARTMARKING DETAIL
- FMMT3903
- 1W FMMT3904
- 1A
FMMT3903 FMMT3904
ABSOLUTE MAXIMUM RATINGS.
PARAMETER Collector-Base Voltage Collector Emitter Voltage Emitter Base Voltage Continuous Collector Current Power Dissipation at Tamb=25°C Operating and Storage Temperature Range
SYMBOL
VCBO VCEO VEBO IC Ptot Tj:Tstg
VALUE 60 40 6 200 330
-55 to +150
UNIT V V V m A m W °C
ELECTRICAL CHARACTERISTICS (at Tamb = 25°C unless otherwise stated).
PARAMETER
FMMT3903 FMMT3904 SYMBOL MIN. MAX. MIN. MAX. UNIT CONDITIONS.
Collector Base
V(BR)CBO 60
Breakdown Voltage
V IC=10µA, IE=0
Collector Emitter V(BR)CEO 40
Breakdown Voltage
V IC=1m A, IB=0-
Emitter Base
V(BR)EBO 6
Breakdown Voltage
V IE=10µA, IC=0
Collector Emitter ICEX Cut Off Current
50 n A VCE=30V, VBE(off)...
