Features - patible with all I2C bidirectional data transfer protocol - Memory array: - 512 Kbits (64 Kbytes) of EEPROM - Page size: 128 bytes - Additional Write lockable page - Single supply voltage and high speed: - 1 MHz - Random and sequential Read modes - Write: - Byte Write within 5 ms - Page Write within 5 ms - Partial Page Writes Allowed - Write Protect Pin for Hardware Data Protection - Schmitt Trigger, Filtered Inputs for Noise Suppression - High-reliability - Endurance: 1 Million Write Cycles - Data Retention: 100 Years - Enhanced ESD/Latch-up protection - HBM 6000V - 8-lead PDIP/SOP/TSSOP/UDFN/WLCSP packages Description - The ZD24C512A provides 524288 bits of serial electrically erasable and programmable read-only memory (EEPROM), organized as 65536 words of 8 bits each. - The ZD24C512A offers an additional page, named the Identification Page (128 bytes). The Identification Page can be used to store sensitive application parameters which can be (later) permanently locked in Read-only mode. - The device is optimized for use in many industrial and mercial applications where low-power and low-voltage operation are essential. Zetta Device Electronics Technology Co.,Ltd .zettadevice. 1 / 19 1. Pin Descriptions and Pinouts Pin Name A0 A1 A2 Vss Table 1-1.Pin...
