FEATURES - Rugged construction for high reliability - Life expectancy greater than 100 million operations - DC coils to 115 V - Power consumption as low as 25 m W per pole available - Current sensitive and voltage sensitive coils available - Round core and large coil volume provide greater pull force - Up to 6 poles in less than one cubic inch - Dry circuit to 5 Amp contacts - Printed circuit or solder/plug-in terminals d - Balanced spring-held armature allows dependable operation in any position - Sealed version available (2 and 4 pole) e - UL, CUR file E43203 CONTACTS u Arrangement DPDT (2 Form C) 4PDT (4 Form C) 6PDT (6 Form C) tin Ratings Material See contact data table under relay ordering data UL Rating: See table for UL approved contact ratings See contact data table under relay ordering data Resistance < 50 milliohms initially n COIL Power At Pickup Voltage o (typical) Max. Continuous c Dissipation Temperature Rise Standard is Sensitive Standard: 450 m W, 2 or 4 pole Sensitive: 80 m W, 2 pole 180 m W, 4 pole (25 m W per pole available) 2.6 W at 20°C (68°F) ambient 2.0 W at 40°C (105°F) ambient 23°C (41°F) at nominal coil voltage,2 or 4 pole 40°C (72°F) at nominal coil voltage, 6 pole 5°C (9°F) at nominal coil voltage, 2 pole 10°C (18°F) at nominal coil voltage, 4 pole Temperature Max. 105°C (221°F) D NOTES GENERAL DATA Life Expectancy Mechanical Electrical Minimum operations 500 million See typical contact life expectancy table Operate Time See typical operate and release time diagram Release Time See typical operate and release time diagram Capacitance (typical) Contact to contact: 2 p F Contact to coil: 2 p F Contact to frame: 30 p F Bounce (typical) At 10 m A contact current 3 ms at nominal coil...
