Datasheet Summary
50 AMP HEAVY DUTY POWER RELAY
Features
- SPST, DPST, SPDT, and DPDT versions available
- AC and DC coils available
- UL Class F (155°C) molded construction
- 900, 900D and 900E are UL and cUL Listed
- 900S. 900Q, and 900R are UL cUR Recognized
- UL, CUL file E44211
CONTACTS
Arrangement SPST ( 1 Form A & B), SPST-NO-DM ( Form 1X), SPST-NC-DB (Form 1Y), DPST ( 2 Form A & B ), SPDT ( 1 Form C), DPDT ( 2 Form C)
Ratings Resistive load:
UL, CUR
Max. switched power: 840 W or 12000 VA Max. switched current: 30 A Max. switched voltage: 600 VAC, 28 VDC 30 A at 240 VAC [1][2][3] 1.5 HP at 120 VAC [1][2][3] 2.0 HP at 240 VAC [1][2][3] 3600 VA at 120 VAC / 240 VAC ballast [1][2][3] 30 A at...
