AO3495
Description
- Low RDS(ON)
- Ro HS and Halogen-Free pliant
Applications
- Load switch
- PWM
20V P-Channel MOSFET
Product Summary
VDS ID (at VGS=-4.5V) RDS(ON) (at VGS= -4.5V) RDS(ON) (at VGS= -2.5V) RDS(ON) (at VGS= -1.8V)
ESD protected
-20V -5A < 41mΩ < 53mΩ < 65mΩ
SOT23
Top View
Bottom View
Absolute Maximum Ratings TA=25°C unless otherwise noted
Parameter
Symbol
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current
TA=25°C TA=70°C
Pulsed Drain Current C
TA=25°C Power Dissipation B TA=70°C
Junction and Storage Temperature Range
TJ, TSTG
Maximum -20 ±8 -5 -4 -30 1.5 1
-55 to 150
Thermal Characteristics
Parameter
Symbol
Typ
Maximum Junction-to-Ambient A t ≤ 10s Maximum Junction-to-Ambient A D...
