AONS62602
Description
- Trench Power Alpha SGTTM technology
- Low RDS(ON)
- Logic Level Gate Drive
- Excellent Gate Charge x RDS(ON) Product (FOM)
- Ro HS and Halogen-Free pliant
Applications
- High Frequency Switching and Synchronous Rectification
Product Summary
VDS ID (at VGS=10V) RDS(ON) (at VGS=10V) RDS(ON) (at VGS=4.5V)
100% UIS Tested 100% Rg Tested
60V 85A < 2.5mΩ < 3.6mΩ
Top View
DFN5x6 Bottom View
PIN1
Orderable Part Number
PIN1
Package Type
DFN 5x6
Top View
Form
Tape & Reel
Minimum Order Quantity
Absolute Maximum Ratings TA=25°C unless otherwise noted
Parameter
Symbol
Drain-Source Voltage
Gate-Source...
