DTQ1127P02
FEATURES
- DT-Trench Power MOSFET
- Surface Mount Package
APPLICATIONS
- Battery operated systems
- Direct logic-level interface: TTL/CMOS
DFN1006-3L
Top View
Bottom View
D P-Channel MOSFET
ABSOLUTE MAXIMUM RATINGS (TJ = 25 °C, unless otherwise noted)
PARAMETER
SYMBOL
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current (TJ = 150 °C)
TA = 25 °C ID
TA = 70 °C
Pulsed Drain Current
Maximum Power Dissipation a
TA = 25 °C PD
TA = 70 °C
Operating Junction and Storage Temperature Range
TJ, Tstg
THERMAL RESISTANCE RATINGS
PARAMETER Junction-to-Ambient (PCB Mount) b
Notes: a. TC = 25 °C. b. Surface mounted on 1" x 1" FR4 board.
SYMBOL Rth JA
LIMIT
- 20 ± 12
- 2.5
- 1.8
- 10 0.27 0.17 -55 to +150
LIMIT 420
UNIT V
A W...
