AM26LS31M
Features
- Meets or exceeds the requirements of ANSI TIA/ EIA-422-B and ITU
- Operates from a single 5V supply
- TTL-patible
- plementary outputs
- High output impedance in power-off conditions
- plementary output-enable inputs
- Available MIL-PRF-38535-qualified options (M):
All parameters are tested unless otherwise noted. On all other products, production processing does not necessarily include testing of all parameters.
2 Applications
- Motor encoders
- Field transmitters: pressure sensors and temperature sensors
- Military and avionics imaging
- Temperature sensors or controllers using modbus
3 Description
The AM26LS31CN-E family of devices is a quadruple plementary-output line driver designed to meet the requirements of ANSI TIA/EIA-422-B and ITU (formerly CCITT) Remendation V.11. The 3state outputs have high-current capability for driving balanced lines such as twisted-pair or parallel-wire transmission lines, and are in the high-impedance state in the power-off condition....
