CSDM65295T
Features
- Topside-cooled 9 mm x 10 mm x 5 mm LGA package, industry mon footprint
- Integrated inductor
- High output current capability:
- Peak current: 180A
- Continuous current: 130A RMS
- (Subject to thermal boundary condition)
- Operating VIN input voltage: 4.5V to 16V
- Operating VDD Bias: 4.5V to 5.5V
- High-frequency operation (up to 2MHz)
- Integrated clamping circuitry for avalanche free operation
- Temperature pensated bi-directional current sense with current mode reporting (5μA/A)
- Body braking mode (BB)
- Forced continuous conduction mode (FCCM) operation
- Green, Ro HS pliant without exemption, and pletely Pb free
- Fault detection
- High-side short (HSS)
- Fault protection
- Over temperature (OT)
- Cycle-by-cycle negative over current limiting
(NOC)
- Over current protection (OCP)
- BOOT UVLO
2 Applications
- Data center and enterprise puting rack server
- Hardware accelerator
- Network interface card (NIC)
- ASIC and high performance client
- ASIC power for networking...
