Texas Instruments HVDA553-Q1
The HVDA55x-Q1 device is designed and qualified for use in automotive applications and meets or exceeds the specifications of the ISO 11898 High Speed CAN (Controller Area Network) Physical Layer standard (transceiver).| Part No. | HVDA553-Q1 |
|---|---|
| Datasheet | HVDA553-Q1 Download |
| Manufacturer |  Texas Instruments |
| Description | 5-V CAN Transceiver |
| Buy | Stock & Price |
FEATURES
● Qualified for AutomotiveAPPLICATIONS
● AEC-Q100 Qualified With the Following Results: – Device Temperature Grade 1: –40°C to +125°C Ambient Operating Temperature – Device HBM ESD Classification Level: – Level 3B for Pins 6 and 7 – Level 3A for All Other Pins – Device CDM ESD Classification Level C6● Meets or Exceeds the Requirements of ISO 11898-2 and ISO 11898-5
● GIFT/ICT Compliant
● Data Rate Up to 1 Mbps
● ESD Protection Up to ±12 kV (Human-Body Model) on Bus Pins
● I/O Voltage Level Adapting – HVDA551: Adaptable I/O Voltage Range (VIO) From 3 V to 5.33 V
● SPLIT Voltage Source – HVDA553: Common-Mode Bus Stabilization
● Operating Modes: – Normal Mode – Low-Power Standby Mode With RXD Wake-Up Request
● High Electromagnetic Compliance (EMC)
● Supports CAN Flexible Data-Rate (FD)
● Protection – Undervoltage Protection on VIO and VCC – Bus-Fault Protection of –27 V to 40 V – TXD Dominant State Time-Out 1 – RXD Wake-Up Request Lockout on CAN Bus Stuck Dominant Fault (HVDA55...
