LM2596 Datasheet 3-a Step-down Voltage Regulator

Manufacturer: Texas Instruments

Overview: LM2596 SNVS124G – NOVEMBER 1999 – REVISED MARCH 2023 LM2596 SIMPLE SWITCHER® Power Converter 150-kHz 3-A Step-Down Voltage Regulator.

General Description

The LM2596 series of regulators are monolithic integrated circuits that provide all the active functions for a step-down (buck) switching regulator, capable of driving a 3-A load with excellent line and load regulation.

These devices are available in fixed output voltages of 3.3 V, 5 V, 12 V, and an adjustable output version.

Requiring a minimum number of external components, these regulators are simple to use and include internal frequency compensation, and a fixedfrequency oscillator.

Key Features

  • New product available:.
  • LMR51430 4.5 to 36-V, 3-A, 500-kHz and 1.1MHz synchronous converter.
  • For faster time to market:.
  • TLVM13630 3 to 36-V, 3-A, 200-kHz to 2.2-MHz power module.
  • 3.3-V, 5-V, 12-V, and adjustable output versions.
  • Adjustable version output voltage range: 1.2-V to 37-V ±4% maximum over line and load conditions.
  • Available in TO-220 and TO-263 packages.
  • 3-A output load current.
  • Input voltage range up t.
