REF3140-Q1 Overview
The REF31xx-Q1 is a family of precision, low power, low dropout, series voltage references available in the tiny 3-pin SOT-23 package. The REF31xx-Q1 small size and low power consumption (100 μA typical) make it ideal for portable and battery-powered applications. The REF31xx-Q1 does not require a load capacitor, but is stable with any capacitive load and can sink or source up to 10 mA of output current.
REF3140-Q1 Key Features
- 1 AEC-Q100 Qualified With the Following Results
- Device TA Range: -40°C to 125°C
- Device HBM ESD Classification Level H1C
- Device CDM ESD Classification Level C4A
- High Accuracy: 0.2% Maximum
- Excellent Specified Drift Performance
- 20 ppm/°C (Maximum) from -40°C to +125°C
- High Output Current: ±10 mA
- Low Dropout: 5 mV
- Low IQ: 115 µA Maximum
