Texas Instruments SM32C6416T-EP
Fixed-Point Digital Signal Processor
| Part No. | SM32C6416T-EP |
|---|---|
| Datasheet | SM32C6416T-EP Download |
| Manufacturer |  Texas Instruments |
| Description | Fixed-Point Digital Signal Processor |
| Buy | Stock & Price |
FEATURES
− Byte-Addressable (8-/16-/32-/64-Bit Data) − 8-Bit Overflow Protection − Bit-Field Extract, Set, Clear − Normalization, Saturation, Bit-Counting − VelociTI.2 Increased Orthogonality D Enhanced Direct-Memory-Access (EDMA) Controller (64 Independent Channels) D Host-Port Interface (HPI) − User-Configurable Bus Width (32-/16-Bit) D 32-Bit/33-MHz, 3.3-V PCI Master/Slave Interface Conforms to PCI Specification 2.2 − Three PCI Bus Address Registers − Four-Wire Serial EEPROM Interface − PCI Interrupt Request Under DSP Program Control − DSP Interrupt Via PCI I/O Cycle D Three Multichannel Buffered Serial Ports − Direct Interface to T1/E1, MVIP, SCSA Framers − Up to 256 Channels Each − ST-Bus-Switching-, AC97-Compatible − Serial Peripheral Interface (SPI) Compatible (Motorola) D Three 32-Bit General-Purpose Timers D UTOPIA [C6416T] − UTOPIA Level 2 Slave ATM Controller − 8-Bit Transmit and Receive Operations up to 50 MHz per Direction − User-Defined Cell Format up to 64 Bytes D 16 G...
