SN54HC00J - Quadruple 2-Input Positive-NAND Gates

This page provides the datasheet information for the SN54HC00J, a member of the SN54HC00 Quadruple 2-Input Positive-NAND Gates family.

Product Overview

Texas Instruments

📥 Download Datasheet

SN54HC00J Quadruple 2-Input Positive-NAND Gates by Texas Instruments - Datasheet Preview — Datasheet preview – SN54HC00J

Datasheet Details

Part number	SN54HC00J
Manufacturer	Texas Instruments
File Size	1.34 MB
Description	Quadruple 2-Input Positive-NAND Gates
Datasheet	SN54HC00J Datasheet
Additional preview pages of the SN54HC00J datasheet.

SN54HC00J Product details

Description

This device contains four independent 2-input NAND Gates.

B in positive logic.

Features

Buffered inputs.
Wide operating voltage range: 2 V to 6 V.
Wide operating temperature range:.
40°C to +85°C.
Supports fanout up to 10 LSTTL loads.
Significant power reduction compared to LSTTL logic ICs 2.
