Datasheet Summary
TL071, TL071A, TL071B, TL071H TL072, TL072A, TL072B, TL072H, TL072M TL074, TL074A, TL074B, TL074H, TL074M
SLOS080W
- SEPTEMBER 1978
- REVISED JULY 2025
TL07xx Low-Noise, FET-Input Operational Amplifiers
1 Features
- High slew rate: 20V/μs (TL07xH, typ)
- Low offset voltage: 1mV (TL07xH, typ)
- Low offset voltage drift: 2μV/°C
- Low power consumption: 940μA/ch (TL07xH, typ)
- Wide mon-mode and differential voltage ranges
- mon-mode input voltage range includes VCC+
- Low input bias and offset currents
- Low noise:
- Vn = 37nV/√Hz (typ) at f = 1kHz
- Output short-circuit protection
- Low total harmonic distortion: 0.003% (typ)
- Wide supply voltage:
- ±2.25V to ±20V, 4.5V to 40V
2...
