TLV1702 - microPower Comparator

This page provides the datasheet information for the TLV1702, a member of the TLV1701 microPower Comparator family.

Description

The TLV170x family of devices offers a wide supply range, rail-to-rail inputs, low quiescent current, and low propagation delay.

Features

  • 1 Supply Range: +2.2 V to +36 V or ±1.1 V to ±18 V.
  • Low Quiescent Current: 55 µA per Comparator.
  • Input Common-Mode Range Includes Both Rails.
  • Low Propagation Delay: 560 ns.
  • Low Input Offset Voltage: 300 µV.
  • Open Collector Outputs:.
  • Up to 36 V Above Negative Supply Regardless of Supply Voltage.
  • Industrial Temperature Range:.
  • 40°C to +125°C.
  • Small Packages:.
  • Single: SC70-5, SOT-23-5, SOT553-5.

📥 Download Datasheet

Datasheet preview – TLV1702

Datasheet Details

Part number TLV1702
Manufacturer Texas Instruments
File Size 2.18 MB
Description microPower Comparator
Datasheet download datasheet TLV1702 Datasheet
Additional preview pages of the TLV1702 datasheet.
