TPL5010 - Nano-Power System Timer

Description

The TPL5010 Nano Timer is an ultra-low power timer with a watchdog feature designed for system wake up in duty-cycled, battery-powered applications such as those in IoT.

Features

  • 1 Supply Voltage From 1.8 V to 5.5 V.
  • Current Consumption at 2.5 V and 35 nA (Typical).
  • Selectable Time Intervals: 100 ms to 7200 s.
  • Timer Accuracy: 1% (Typical).
  • Resistor Selectable Time Interval.
  • Watchdog Functionality.
  • Manual Reset 2.
