TPS62160 - 3-V to 17-V 1-A Step-Down Converters

Description

The TPS6216x device family are easy to use synchronous step-down DC/DC converters optimized for applications with high power density.

Features

  • 1 DCS-Control™ Topology.
  • Input Voltage Range from 3 V to 17 V.
  • Up to 1-A Output Current.
  • Adjustable Output Voltage From 0.9 V to 6 V.
  • Fixed Output Voltage Versions.
  • Seamless Power Save Mode Transition.
  • Typically 17-µA Quiescent Current.
  • Power Good Output.
  • 100% Duty Cycle Mode.
  • Short Circuit Protection.
  • Over Temperature Protection.
  • Pin to Pin Compatible With TPS62170 and TPS62125.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
TPS621 NPN Photo Transistor Toshiba Semiconductor
TPS622 Silicon NPN Transistor Toshiba Semiconductor
TPS622F Silicon NPN Transistor Toshiba Semiconductor
TPS625 NPN Photo Transistor Toshiba Semiconductor
TPS626 NPN Photo Transistor Toshiba Semiconductor

Other Datasheets by Texas Instruments

Part Number Description
TPS62160-Q1 3-V to 17-V 1-A Step-Down Converter
TPS62161 3-V to 17-V 1-A Step-Down Converters
TPS62162 3-V to 17-V 1-A Step-Down Converters
TPS62162-Q1 3-V to 17-V 1-A Step-Down Converter
TPS62163 3-V to 17-V 1-A Step-Down Converters

Full PDF Text Transcription

Click to expand full text
Product Folder Order Now Technical Documents Tools & Software Support & Community Reference Design TPS62160, TPS62161, TPS62162, TPS62163 SLVSAM2E – NOVEMBER 2011 – REVISED MAY 2017 TPS6216x 3-V to 17-V, 1-A Step-Down Converters with DCS-Control™ 1 Features •1 DCS-Control™ Topology • Input Voltage Range from 3 V to 17 V • Up to 1-A Output Current • Adjustable Output Voltage From 0.9 V to 6 V • Fixed Output Voltage Versions • Seamless Power Save Mode Transition • Typically 17-µA Quiescent Current • Power Good Output • 100% Duty Cycle Mode • Short Circuit Protection • Over Temperature Protection • Pin to Pin Compatible With TPS62170 and TPS62125 • Available in 3.00 mm x 3.00 mm 8-Pin VSSOP and 2.00 mm × 2.
