TPS62876-Q1 - Synchronous Step-Down Converter

Download the TPS62876-Q1 datasheet PDF (TPS62874-Q1 included). The manufacturer datasheet provides complete specifications, pinout details, electrical characteristics, and typical applications for synchronous step-down converter.

Description

The TPS62874-Q1, TPS62875-Q1, TPS62876-Q1 and TPS62877-Q1 are a family of pin-to-pin, 15A, 20A, 25A, and 30A synchronous step-down DC/DC converters with I2C interface and differential remote sense.

All devices offer high efficiency and ease of use.

Features

  • AEC-Q100 qualified for automotive.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (TPS62874-Q1-etcTI.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

  • TPS621 - NPN Photo Transistor (Toshiba Semiconductor)
  • TPS622 - Silicon NPN Transistor (Toshiba Semiconductor)
  • TPS622F - Silicon NPN Transistor (Toshiba Semiconductor)
  • TPS625 - NPN Photo Transistor (Toshiba Semiconductor)
  • TPS626 - NPN Photo Transistor (Toshiba Semiconductor)
  • TPS603A - Photo Transistor (Toshiba Semiconductor)
  • TPS604 - POWER SCHOTTKY RECTIFIER (STMicroelectronics)
  • TPS606 - TERMINAL OPTO-ELECTRONIC SWITCH (Toshiba Semiconductor)
  • TPS60LB - SWITCHING MODE 60W LOW COST BOX TYPE POWER SUPPLY (Total Power International)
  • TPS611 - Phototransistor (Toshiba)
Other Datasheets by Texas Instruments

Full PDF Text Transcription

Click to expand full text
TPS62874-Q1, TPS62875-Q1, TPS62876-Q1, TPS62877-Q1 SLVSFU1D – APRIL 2023 – REVISED DECEMBER 2024 TPS6287x-Q1 2.7V to 6V Input, 15A, 20A, 25A, and 30A Automotive, Fast Transient, Synchronous Step-Down Converter With I2C Interface 1 Features • AEC-Q100 qualified for automotive applications – Device temperature grade 1: –40°C to 125°C TA – –40°C to 150°C junction temperature range • Functional Safety-Capable – Documentation available to aid functional safety system design • Input voltage range: 2.7V to 6V • Family of pin-to-pin compatible devices: 15A, 20A, 25A, and 30A • Three selectable output voltage ranges from 0.4V to 1.675V – 0.4V to 0.71875V with 1.25mV steps – 0.4V to 1.0375V with 2.5mV steps – 0.4V to 1.675V with 5mV steps • Output voltage accuracy: ±0.
