Product details

Description

The 74HC04; 74HCT04 is a hex inverter.

Features

Wide supply voltage range from 2.0 V to 6.0 V.
CMOS low power dissipation.
High noise immunity.
Latch-up performance exceeds 100 mA per JESD 78 Class II Level B.
Complies with JEDEC standards:.
JESD8C (2.7 V to 3.6 V).
JESD7A (2.0 V to 6.0 V).
Input levels:.
For 74HC04: CMOS level.
For 74HCT04: TTL level.
ESD protection:.
HBM JESD22-A114F exceeds 2000 V.
MM JESD22-A115-A exceeds.
