BC817-16 - 500mA NPN general-purpose transistors

Download the BC817-16 datasheet PDF. This datasheet also covers the BC817 variant, as both devices belong to the same 500ma npn general-purpose transistors family and are provided as variant models within a single manufacturer datasheet.

General Description

NPN general-purpose transistors in a small SOT23 Surface-Mounted Device (SMD) plastic package.

Table 1.

Key Features

  • High current.
  • Three current gain selections.
  • AEC-Q101 qualified 1.3.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (BC817-nexperia.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number BC817-16
Manufacturer Nexperia
File Size 278.86 KB
Description 500mA NPN general-purpose transistors
Datasheet download datasheet BC817-16 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
BC817-16 45V NPN SMALL SIGNAL TRANSISTOR Diodes Incorporated
BC817-16 NPN Small Signal Transistor Micro Commercial Components
BC817-16 NPN general purpose transistor NXP
BC817-16 NPN Silicon AF Transistors Infineon Technologies AG
BC817-16 SMD General Purpose NPN Transistors Diotec

Other Datasheets by Nexperia

Part Number Description
BC817-16QB-Q 500mA NPN general-purpose transistors
BC817-16QCH-Q 500mA NPN general-purpose transistors
BC817-25 500mA NPN general-purpose transistors
BC817-25QA 500mA NPN general-purpose transistors
BC817-25QB-Q 500mA NPN general-purpose transistors

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
BC817 series 45 V, 500 mA NPN general-purpose transistors Rev. 7 — 18 June 2018 Product data sheet 1 Product profile 1.1 General description NPN general-purpose transistors in a small SOT23 Surface-Mounted Device (SMD) plastic package. Table 1. Product overview Type number Package Nexperia BC817 SOT23 BC817-16 BC817-25 BC817-40 JEDEC TO-236AB JEITA - PNP complement BC807 BC807-16 BC807-25 BC807-40 1.2 Features and benefits • High current • Three current gain selections • AEC-Q101 qualified 1.3 Applications • General-purpose switching and amplification Nexperia BC817 series 45 V, 500 mA NPN general-purpose transistors 1.4 Quick reference data Table 2. Quick reference data Tamb = 25 °C unless otherwise specified.
