N55PA01 Datasheet (Nuvoton Technology)

Part N55PA01
Description 1W PWM Power Amplifier
Manufacturer Nuvoton Technology
Size 471.77 KB
N55PA01 Datasheet (PDF) Download
Pricing from 0.2644 USD, available from Classic Components and NAC Semi.
🏠
Nuvoton Technology

N55PA01 Overview

Description

The N55PA01 is an amplifier to amplify output signal (max. 1W @5.5V) from PWM and/or MIC Linein.

Key Features

  • Operation Voltage
  • 2.0V ~ 5.5 V
  • Accept both PWM signal without external components
  • Mute Function
  • Standby current: typical 1.8uA
N55PA01 datasheet preview

Price & Availability

Seller Inventory Price Breaks Buy
Classic Components 4441 - View Offer
NAC Semi 3541 1900+ : 0.2644 USD
3541+ : 0.2404 USD		 View Offer
