Nuvoton Technology NUC945ADN
This chip is built around an outstanding CPU core: the 16/32 ARM926EJ-S RISC processor designed by Advanced RISC Machines, Ltd. The ARM926EJ-S core, offers 8K-byte I-cache and 8K-byte D-cache with MMU.| Part No. | NUC945ADN |
|---|---|
| Datasheet | NUC945ADN Download |
| Manufacturer |  Nuvoton Technology |
| Description | 32-bit ARM926EJ-S Based Microcontroller |
| Buy | Stock & Price |
GENERAL DESCRIPTION
One 10/100 Mb MAC of Ethernet controller is built-in to reduce total system cost. This micro-controller is suitable for a high end, high performance and low cost related products as well as general purpose applications. The following integrated on-chip functions are described in detail in this document. CPU Platform Networking USB Interface Storage Interface Peripheral & Misc. MAIN FUNCTION● ARM926EJ-S
● Programmable PLL System Clock Synthesizer
● AMBA Peripherals
● Timer
● Advanced Interrupt Controller
● External Bus Interface Controller
● Ethernet MAC Controller
● USB 1.1/2.0 High/Full/Low Speed Host Controller
● 2.0 High/Full Speed Device Controller
● SD/SDIO Controller
● GPIO
● UART Publication Release Date: Jun. 18, 2010 4 Revision: A5 NUC945ADN 32-BIT ARM926EJ-S BASED MCU 2
FEATURES
Architecture● Efficient and powerful ARM926EJ-S core with fully 16/32-bit RISC architecture
● Little Endian mode supported
● 8K-byte I-cache and 8K-byte D-cache with MMU Power ma...
