Nuvoton Technology W83601G
The W83601G are general purpose input/output ICs with SMBusTM( I2C ). The W83601G provides 15 GPI/O pins. The W83601G provides SMBusTM (I2C) address setting pins to set the address during power- on reset or from external reset.| Part No. | W83601G |
|---|---|
| Datasheet | W83601G Download |
| Manufacturer |  Nuvoton Technology |
| Description | GPI/O Expander |
| Buy | Stock & Price |
GENERAL DESCRIPTION
The W83601G provides 15 GPI/O pins. SMBusTM Address of the W83601G is: 0 0 1 1 A2 A1 A0 R/W The W83601G also provides an interrupt to inform the system that a transition occurs on General Purpose (GP) input pins. 2.FEATURES
y SMBus compliance with 3.3V voltage levels y Two GPI/O ports which provides more flexibility y Issue interrupts to notify the system that an event occurs y GP output can be level or pulse mode y Interrupt output can be in the level or pulse mode y Internal power-on reset or external RST# pin reset y Programmable POWER LED output 3. PACKAGE y The W83601G is 20-pin SSOP Pb-free (RoHS compatible) package. Publication Release Date: Mar, 2009 -2- Revision 1.31 W83601G 4. KEY SPECIFICATIONS y Supply Voltage 5V y Operating Supply Current 1 mA typ. y Operating Temperature 0 - 70 °C 5. PIN CONFIGURATION SCLK SDAT GP20/A0 GP21/A1 GP22/A2 GP10 GP11 GP23 GP24 VSS W83601G 1 20 2 19 3 18 4 17 5 16 6 15 7 14 8 13 9 12 10 11 20SSOP VDD RST# GP17/INT GP16 GP15 GP14 GP13 GP12 GP26/INT GP25 6.
