BCX56-10R1
Preferred Device
NPN Silicon Epitaxial Transistor
These NPN Silicon Epitaxial transistors are designed for use in audio amplifier applications. The device is housed in the SOT-89 package, which is designed for medium power surface mount applications.
- High Current: 1.0 Amp
- Available in 7 inch/1000 unit Tape and Reel
- Device Marking: BK
MAXIMUM RATINGS (TC = 25°C unless otherwise noted)
Rating
Symbol
Value
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage
Collector Current
Total Power Dissipation @ TA = 25°C Derate above 25°C
VCEO
VCBO
VEBO
(Note 1.)
(Note 2.)
Operating and Storage Temperature Range
TJ, Tstg
- 65 to 150
THERMAL CHARACTERISTICS
Characteristic
Symbol
Max
Thermal Resistance Junction-to-Ambient (surface mounted)
RθJA
(Note 1.)
(Note...
