NTBG1000N170M1
Features
- Typ. RDS(on) = 960 m W
- Ultra Low Gate Charge (typ. QG(tot) = 14 n C)
- Low Effective Output Capacitance (typ. Coss = 11 p F)
- 100% Avalanche Tested
- Ro HS pliant
Typical Applications
- Solar Inverters
- Electric Vehicle Charging Stations
- Electric Storing Systems
- SMPS (Switch Mode Power Supplies)
- UPS (Uninterruptible Power Supplies)
MAXIMUM RATINGS (TJ = 25°C unless otherwise noted)
Parameter
Symbol Value Unit
Drain- to- Source Voltage
Gate- to- Source Voltage
Remended Operation Values of Gate- to- Source Voltage
TC < 175°C
VDSS
- 15/+25 V
VGSop
- 5/+20 V
Continuous Drain Current (Note 2)
Steady TC = 25°C
State
Power Dissipation (Note 2)
Continuous Drain Current (Note 2)
Steady TC = 100°C
State
Power Dissipation (Note 2)
Pulsed Drain Current (Note...
