NVH4L016N065M3S
Features
- Typical RDS(on) = 16 m W @ VGS = 18 V
- Low Effective Output Capacitance
- Ultra Low Gate Charge
- 100% UIS Tested
- Qualified According to AECQ101
- This Device is Halide Free and Ro HS pliant with Exemption 7a,
Pb-Free 2LI (on second level interconnection)
Applications
- Automotive On and Off Board Charger
- Automotive DC-DC Converter for EV-HEV
MAXIMUM RATINGS (TJ = 25°C unless otherwise noted)
Parameter
Symbol Value Unit
Drain-to-Source Voltage Gate-to-Source Voltage Continuous Drain Current Power Dissipation Continuous Drain Current Power Dissipation Pulsed Drain Current (Note 1) Continuous Source-Drain Current (Body Diode)
Pulsed Source-Drain Current (Body Diode) (Note 1) Single Pulse Avalanche Energy (Note 2)
TC = 25 °C
TC = 100 °C
TC = 25 °C tp = 100 ms TC = 25 °C VGS =
- 3 V TC = 100 °C VGS =
- 3 V TC = 25 °C VGS =
- 3 V, tp = 100 ms ILPK = 60 A, L = 0.1 m H
VDSS
- 10/+22.6...
