SNXH225B95H4Q2F2PG
Features
- Extremely Efficient Trench with Field Stop Technology
- Low Switching Loss Reduces System Power Dissipation
- Module Design Offers High Power Density
- Low Inductive Layout
- Q2BOOST Package with Press- Fit Pins
- 1200 V Si C Diode
Typical Applications
- Solar Inverters
- UPS Systems
18,25
DATA SHEET .onsemi.
Q2BOOST MODULE CASE 180AV
MARKING DIAGRAM
SNXH225B95H4Q2F2PG ATYYWW
FRONTSIDE MARKING
2D CODE
BACKSIDE MARKING
= Pb- Free Package
= Assembly & Test Site Code
YYWW = Year and Work Week Code
PIN CONNECTIONS
18 19 20 17
10...
