OP07C Datasheet and Specifications PDF

The OP07C and OP07D (OP07x) devices offer low offset and long-term stability by means of a lownoise, chopperless, bipolar‑input‑transistor amplifier circuit. For most applications, external component.

* Low noise
* No external components required
* Replace chopper amplifiers at a lower cost
* Wide input-voltage range: 0 V to ±14 V (typ, ±15-V supply)
* Wide supply-voltage range: ±3 V to ±18 V 2 Applications
* Analog input module
* Battery test
* Lab and field instrumentation
* Temperature transmi.

The OP07C is a very high precision op amp with an offset voltage maximum of 150µV. Offering also low input current (1.8nA) and high gain (400V/mV), the OP07C is particularly suitable for instrumentati.

LLING CIRCUIT Offset Null 1 Offset Null 2 20kΩ VCC ABSOLUTE MAXIMUM RATINGS Symbol VCC Vid Vi Toper Tstg Supply Voltage Differential Input Voltage Input Voltage Operating Temperature Storage Temperature Parameter Value ±22 ±30 ±22 -40 to +105 -65 to +150 Unit V V V o o C C 2/4 OP07C ELECTRICAL.
