| Part Number | RS1006FL Datasheet |
|---|---|
| Manufacturer | PanJit Semiconductor |
| Overview |
RS1001FL~RS1010FL
SMALL SURFACE MOUNT FAST DIODES
VOLTAGE 100 to 1000 Volts CURRENT 1.0 Amperes
FEATURES
• For surface mounted applications • Low profile package • Ideal for automated placement • Glas.
* For surface mounted applications * Low profile package * Ideal for automated placement * Glass Passivated Chip Junction * High temperature soldering : 260OC / 10 seconds at terminals * In compliance with EU RoHS 2002/95/EC directives MECHANICAL DATA * Case : JEDEC SOD-123FL, Molded plastic over pa. |
RS1006FL Datasheet and Specifications PDF
The RS1006FL is a SMALL SURFACE MOUNT FAST DIODES.
| Part Number | RS1006FL Datasheet |
|---|---|
| Description | SURFACE MOUNT FAST DIODE |
| Manufacturer | Unisonic Technologies |
| Overview |
The UTC RS1006FL is a surface mount fast diode, it uses UTC’s advanced technology to provide customers with fast switching and low reverse leakage, etc.
The UTC RS1006FL is suitable for surface mounte.
* Fast switching * Low profile package * Low reverse leakage
* SYMBOL DIODE SOD-123F * ORDERING INFORMATION Ordering Number RS1006FLG-CA2F-R Note: Pin Assignment: A: Anode K: Cathode Package SOD-123F Pin Assignment 12 KA Packing Tape Reel * MARKING R6FG Copyright © 2014 Un. |
| Part Number | RS1006FL Datasheet |
|---|---|
| Description | 1.0A SURFACE MOUNT GLASS PASSIVATED FAST RECOVERY DIODE |
| Manufacturer | Won-Top Electronics |
| Overview |
® WON-TOP ELECTRONICS
RS1000FL – RS1010FL
1.0A SURFACE MOUNT GLASS PASSIVATED FAST RECOVERY DIODE
Pb
Features
Low Profile 1.08mm Max. Case Height
Glass Passivated Die Construction
Low Forwa.
* Low Profile 1.08mm Max. Case Height * Glass Passivated Die Construction * Low Forward Voltage Drop, High Efficiency * Surge Overload Rating to 30A Peak * Fast Recovery Time C * Ideally Suited for Automatic Assembly * Plastic Material * UL Recognition Flammability Classification 94V-0 E . |
| Part Number | RS1006FL Datasheet |
|---|---|
| Description | FAST RECOVERY RECTIFIER |
| Manufacturer | JieJie Microelectronics |
| Overview | Plastic package has underwriters laboratory flammability classification 94V-0 Exceeds environmental standards of MIL-S-19500/228 Glass passivated chip junction Lead free in compliance with EU RoHS 20. F(AV) 1.0 A Peak forward surge current: 8.3ms single half sine-wave superimposed IFSM 30 A on rated load (JEDEC method) Maximum forward voltage@ IF=1A VF 1.3 V Maximum DC reverse Tj=25℃ current at rated DC IR blocking voltage Tj=150℃ 5.0 µA 200 µA Typical junction capacitance V. |
