Electrical Characteristics (TJ=25°C unless otherwise noted)
Min Typ Max Units
BVDSS Drain-Source Breakdown Voltage
IDSS Zero Gate Voltage Drain Current
Gate-Body leakage current
Gate Threshold Voltage
On state drain current
RDS(ON) Static Drain-Source On-Resistance
5.8 7.5 mΩ
gFS Forward Transconductance
VSD Diode Forward Voltage
IS Maximum Body-Diode Continuous Current
5.5 7.2 mΩ
Ciss Input Capacitance
Coss Output Capacitance
Crss Reverse Transfer Capacitance
Rg Gate resistance
VGS=0V, VDS=50V, f=1MHz
VGS=0V, VDS=0V, f=1MHz
Qg(10V) Total Gate Charge
85 107 129 nC
Qgs Gate Source Charge
VGS=10V, VDS=50V, ID=20A
23 28.5 34 nC
Qgd Gate Drain Charge
24 40 56 nC
Turn-On Rise Time
VGS=10V, VDS=50V, RL=2.5Ω,
tf Turn-Off Fall Time
trr Body Diode Reverse Recovery Time IF=20A, dI/dt=500A/µs
19 27 35 ns
Qrr Body Diode Reverse Recovery Charge IF=20A, dI/dt=500A/µs
124 177 230 nC
A. The value of RθJA is measured with the device mounted on 1in2 FR-4 board with 2oz. Copper, in a still air environment with TA =25°C. The
Power dissipation PDSM is based on R θJA and the maximum allowed junction temperature of 150°C. The value in any given application depends
on the user's specific board design, and the maximum temperature of 175°C may be used if the PCB allows it.
B. The power dissipation PD is based on TJ(MAX)=175°C, using junction-to-case thermal resistance, and is more useful in setting the upper
dissipation limit for cases where additional heatsinking is used.
C. Repetitive rating, pulse width limited by junction temperature TJ(MAX)=175°C. Ratings are based on low frequency and duty cycles to keep
initial TJ =25°C.
D. The RθJA is the sum of the thermal impedence from junction to case RθJC and case to ambient.
E. The static characteristics in Figures 1 to 6 are obtained using <300µs pulses, duty cycle 0.5% max.
F. These curves are based on the junction-to-case thermal impedence which is measured with the device mounted to a large heatsink, assuming
a maximum junction temperature of TJ(MAX)=175°C. The SOA curve provides a single pulse rating.
G. The maximum current limited by package.
H. These tests are performed with the device mounted on 1 in2 FR-4 board with 2oz. Copper, in a still air environment with TA=25°C.
