Datasheet Summary
S32K3XX
S32K3xx Data Sheet
Rev. 12
- 10 July 2025
Product Data Sheet
Supports S32K344, S32K324, S32K314, S32K312, S32K311, S32K310, S32K341, S32K342, S32K322, S32K328, S32K338, S32K348, S32K356, S32K358 and S32K388. Data is preliminary for S32K389.
This document includes key information in the file attached to it. See the attachment icon in the PDF window to see the list of attachments.
- Operating characteristics
- Voltage range: 2.97 V to 5.5 V
- Ambient temperature range: -40 °C to 125 °C for all power modes
- Arm™ Cortex-M7 core, 32-bit CPU
- M7 supports up to 320 MHz frequency
- Arm Core based on the Armv7 and Thumb®-2 ISA
- Integrated Digital Signal Processor (DSP)
- Configurable...
