GD450HTX75P7SB IGBT

GD450HTX75P7SB Features

* Low VCE(sat) Trench IGBT technology

* Low switching losses

* 6μs short circuit capability

* VCE(sat) with positive temperature coefficient

* Maximum junction temperature 175oC

* Low inductance case

* Fast & soft reverse recovery anti-parallel FWD

* Isolated copper b

Datasheet Details

GD450HTX75P7SB

STARPOWER

655.96 KB

Igbt.
