SN74HC04 Key Features
- Buffered inputs
- Wide operating voltage range: 2 V to 6 V
- Wide operating temperature range
- 40°C to +85°C
- Supports fanout up to 10 LSTTL loads
- Significant power reduction pared to LSTTL
- Part: SN74HC04
- Description: Hex Inverters
- Manufacturer: Texas Instruments
- Size: 1.81 MB
