S-93C86C Datasheet, E2prom, ABLIC

S-93C86C Features

• E2prom
• Memory capacity S-93C46C: 1 K-bit (64-word × 16-bit) S-93C56C: 2 K-bit (128-word × 16-bit) S-93C66C: 4 K-bit (256-word × 16-bit) S-93C76C: 8 K-bit (512-word × 16-bit)

PDF File Details

Part number:

S-93C86C

Manufacturer:

ABLIC

File Size:

536.43kb

Download:

📄 Datasheet

Description:

3-wire serial e2prom. Chip select input Serial clock input Serial data input Serial data output Ground Test No connection Power supply 2. 8-Pin TSSOP Top
