ADAM24P16ST, ADAM24P16S - 4-BIT SINGLE-CHIP MICROCONTROLLERS

ABOV

📥 Download Datasheet

ADAM24P16ST Datasheet Preview — This datasheet PDF includes multiple part numbers: ADAM24P16ST, ADAM24P16S. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: ADAM24P16ST, ADAM24P16S
Manufacturer: ABOV
File Size: 324.51 KB
Datasheet: ADAM24P16S-ABOV.pdf
Description: 4-BIT SINGLE-CHIP MICROCONTROLLERS
Note: This datasheet PDF includes multiple part numbers: ADAM24P16ST, ADAM24P16S.
Please refer to the document for exact specifications by model.

ADAM24P16ST Product details

Features

Program memory.
512 bytes (512 x 8bit).
Data memory (RAM).
16 nibble (16 x 4bit).
3 levels of subroutine nesting.
8-bit Table Read Instruction.
Oscillator Type (Operating frequency).
Internal RC Oscillator (typically 3.64MHz ±2%).
Instruction cycle.
fOSC/48.
Stop mode.
Released stop mode by key input.
Built in Power-on Reset circuit.
Built in Transistor for I. R LED Drive.
IOL=250mA at VDD=3V and VO=0.3V.
Built in Lo.
