HG-0713 Datasheet - AKM

HG-0713 GaAs Hall Element

HG-0713 Absolute Maximum Ratings Item Symbol Conditions Max. Input Voltage Max.Input Power P Operating Temp. Range Topr Storage Temp. Range TSTG Ta=25 Limit 12 150 40 125 40 150 Unit V mW Electrical Characteristics(Ta=25 ) Item Symbol Conditions Min. Typ. Max. Unit Output Hall Voltage VH B=50mT, VC=6V 78 130 102 mV Input Resistance Rin B=0mT, IC =0.1mA Output Resistance Rout B=0mT, IC =0.1mA 1,000 17,25500 1,500 1,800 27,55000 3,000 Offset Voltage Temp. Coefficient of VH Temp. C.
