AWB312 Datasheet, Mmic, ASB

AWB312 Features

  • Mmic
  • 5 ~ 1200 MHz Bandwidth
  • 12.4 dB Gain at 500 MHz
  • Output Power: 101 dBV
  • 2.8 dB NF at 500MHz
  • Robust under Hard Operating Conditions
  • <

PDF File Details

Part number:

AWB312

Manufacturer:

ASB

File Size:

723.03kb

Download:

📄 Datasheet

Description:

Wide-band catv linear amplifier mmic. AWB512, a wide-band linear amplifier MMIC, has high linearity and low noise over a wide range of frequency from 5 MHz to 1200 MHz, be

Datasheet Preview: AWB312 📥 Download PDF (723.03kb)
Page 2 of AWB312 Page 3 of AWB312

AWB312 Application

  • Applications
  • CATV forward at 50 ~ 1200 MHz
  • CATV reverse at 5 ~ 300 MHz
  • Optical Node, FTTH, RFoG 1.4 Package Profile &
