ATA6844 Datasheet, Driver, ATMEL

ATA6844 Features

• Driver
• Broad operation voltage range from 5.25V to 32V
• Atmel® ATA6843 temperature range TJ = 150°C
• Atmel ATA6844 extended temperature range TJ = 200°C
• D

PDF File Details

Part number:

ATA6844

Manufacturer:

ATMEL

File Size:

793.04kb

Download:

📄 Datasheet

Description:

Bldc motor driver. The Atmel® ATA6843 and Atmel ATA6844 are system basis chips for three-phase brushless DC motor controllers designed in Atmel’s state-

ATA6844 Application

• Applications In addition, the circuits provide a 3.3V/5V linear regulator and a window watchdog. The circuit includes various control and protectio
