EMK316BJ105KL

Low Drop Output Voltage Regulator

AUK corp

EMK316BJ105KL Features

* Low dropout voltage regulator

* Low quiescent current and guaranteed 150mA output

* Zero off-mode current Ordering Information Type NO. S52xxM Marking 5

* : Voltage Code Package Code SOT - 25 Outline Dimensions BLOCK DIAGRAM unit : mm

EMK316BJ105KL General Description

The S52xxM is a u-cap 150mA linear voltage regulator in the SOT-25 package. This regulator has very low dropout voltage and very low ground current. It is designed especially for hand-sets, battery-powered devices and can be controlled by a CMOS or TTL. When the S52xxM is disabled, power consumption.

EMK316BJ105KL Datasheet (365.24 KB)

EMK316BJ105KL Datasheet Preview — Preview of EMK316BJ105KL PDF

Datasheet Details

Part number:

EMK316BJ105KL

Manufacturer:

AUK corp

File Size:

365.24 KB

Description:

Low drop output voltage regulator.
