ADNS-6130-001

Laser Mouse Trim Lens

ADNS-6130-001 Features

* is available. These features are useful in maintaining proper positioning and alignment of the ADNS-6120 or ADNS-6130-001 laser mouse lens when used with the Avago Technologies Laser Mouse Sensor. This file can be obtained by contacting your local Avago Technologies sales representative. Figure 4. I

ADNS-6130-001 General Description

The ADNS-6130-001 laser mouse lens are designed for use with Avago Technologies laser mouse sensors and the illumination subsystem provided by the ADNS-6230001 VCSEL assembly clip and the ADNV-6330 or ADNV6340 Single-Mode Vertical-Cavity Surface Emitting Lasers (VCSEL). Together with the VCSEL, the .

ADNS-6130-001 Datasheet (201.91 KB)

Preview of ADNS-6130-001 PDF

Datasheet Details

Part number:

ADNS-6130-001

Manufacturer:

AVAGO

File Size:

201.91 KB

Description:

Laser mouse trim lens.
