ATM0500D13-T
DESCRIPTION
AZ DISPLAYS
ATM0500D13-T(AZ DISPLAYS)TFT MODULE V1.2
※ CONTENTS
1. GENERAL SPECIFICATIONS 2. PIN ASSIGNMENT 3. OPERATING SPECIFICATIONS 4. OPTICAL SPECIFICATIONS 5. RELIABILITY TEST 6. PRECAUTION FOR USING LCM 7. MECHANICAL DRAWING 8. PACKAGE DRAWING 9. INSPECTION SPECIFICATION
AZ DISPLAYS
ATM0500D13-T(AZ DISPLAYS)TFT MODULE V1.2
1. GENERAL SPECIFICATIONS
Item 1. LCD size 2. Driver element 3. Resolution 4. Display mode 5. Dot Pitch (W- H) 6. Pixel pitch(W- H) 7. Active Area(W- H) 8. Module size (W- H) 9. Surface treatment 10. Color arrangement 11. Color 12. Interface 13. Weight 14. Ro HS
Specification 5.0 inch(Diagonal) a-Si TFT active matrix 800x(RGB)x480 Normally white , Transmissive 0.045mm(W) x 0.135mm(H) 0.135mm(W) x 0.135mm(H) 108.0mm(W) x 64.8mm(H) 120.7mm(W) x 75.8mm(H) x4.2mm(D) Anti-glare RGB-stripe 16.7M 24bit RGB interface T.B.D. Ro HS pliant
Remark Note 1
Note 1: Please refer to mechanical drawing.
AZ DISPLAYS
ATM0500D13-T(AZ DISPLAYS)TFT MODULE...
