datasheet Preview Page 1 from Datasheet4u.com

S3028 SILICON ABRUPT VARACTOR DIODE

S3028 SILICON ABRUPT VARACTOR DIODE .
The ASI S3028 is a Designed for use in general purpose filter and oscillator applications. Blue Cathode dot.

S3028_AdvancedSemiconductor.pdf

S3028 Datasheet Preview — Preview of S3028 PDF

Datasheet Details

Part number:

S3028

Manufacturer:

Advanced Semiconductor

File Size:

16.10 KB

Description:

SILICON ABRUPT VARACTOR DIODE

Features

* Blue Cathode dot
* Hermetic sealed Package MAXIMUM RATINGS IF VR PDISS TJ TSTG Tsoldering 10 mA 50 V 1.5 W @ TC = 25 °C -65 °C to +150 °C -65 °C to +150 °C +230 °C for 30 Seconds CHARACTERISTICS SYMBOL VF VBR CJ6 CJ45 ∆ FC TC = 25 °C TEST CONDITIONS IF = 100 mA IR = 10 µA VR =
