HCPL-316J Datasheet, optocoupler equivalent, Agilent

HCPL-316J Features

• Optocoupler
• Drive IGBTs up to IC = 150 A, VCE = 1200 V
• Optically Isolated, FAULT Status Feedback
• SO-16 Package
• CMOS/TTL Compatible
• 500 ns Max. Swit

PDF File Details

Part number:

HCPL-316J

Manufacturer:

Agilent

File Size:

498.30kb

Download:

📄 Datasheet

Description:

2.0 amp gate drive optocoupler.
