A8186SLU Datasheet - Allegro MicroSystems

A8186SLU - LOW-DROPOUT/ 3.3 V REGULATOR . HIGH EFFICIENCY

8186 LOW-DROPOUT, 3.3 V REGULATOR 8186 LOW-DROPOUT, 3.3 V REGULATOR HIGH EFFICIENCY Designed specifically to meet the requirement for extended operation of battery-powered equipment such as cordless and cellular telephones, the A8186SLU voltage regulator offers the reduced dropout voltage and quiescent current essential for maximum battery life.

Applicable also to palmtop computers and personal data assistants, the device delivers a regulated, continuous 3.3 V output at up to 75 mA un

A8186SLU Features

* s High Efficiency Provides Extended Battery Life s 85 mV Typical Dropout Voltage at IO = 60 mA s 45 µA Typical Quiescent Current at V I = 6 V Less Than 1 µA “Sleep” Current s Up to 150 mA Output Current s CMOS-Compatible ON/OFF Control For Power-Up, Standby, or Shutdown s Internal Thermal Protectio

A8186SLU_AllegroMicroSystems.pdf

Preview of A8186SLU PDF
A8186SLU Datasheet Preview Page 2 A8186SLU Datasheet Preview Page 3

Datasheet Details

Part number:

A8186SLU

Manufacturer:

Allegro MicroSystems

File Size:

76.90 KB

Description:

Low-dropout/ 3.3 v regulator . high efficiency.
