CT220 High-Resolution TMR Current Sensor

📥 Download Datasheet  Datasheet Preview Page 1

Description

CT220 XtremeSense™ High-Linearity, High-Resolution TMR Current Sensor with FLAG Output in Miniature Form Factor .
The CT220 is a high-linearity and high-resolution contactless current sensor from Allegro developed on its patented XtremeSense™ TMR technology.

📥 Download Datasheet

Preview of CT220 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Specifications

Part number
CT220
Manufacturer
Allegro
File Size
2.30 MB
Datasheet
CT220-Allegro.pdf
Description
High-Resolution TMR Current Sensor

Features

* AC or DC contactless current sensing
* Inherently high isolation
* Magnetic field (current) range:
* ±1.5 mT
* ±5.0 mT
* ±10.0 mT
* ±15.0 mT
* Stable performance over temperature
* Supply current: ~1.2 mA
* FLAG Pin to

Applications

* Contactless current sensing measurements
* Motor control
* Solar inverters
* Power distribution units (PDUS)
* UPS, SMPS, and telecom power supplies
* Smart appliances
* IoT smart plugs/energy devices
* Battery management systems
